Description

Castrol Optigear? 1100 Range (previously called Tribol? 1100 Range) of high-performance extreme pressure gear

oils, developed to tackle wear-related problems in heavily loaded industrial gears and bearings. Developed for service in

enclosed gear drives, sliding and rolling bearings, the Optigear 1100 gear oils are typically used where heavy and shock

load conditions prevail.

Optigear 1100 is formulated with Tribol Gear Oil Additive (TGOA) Plastic Deformation (PD) additive. TGOA PD helps

improve performance when operating temperature and loads reach a certain level of activation energy, by enabling the

microsmoothing of surface roughness without increasing wear. The smoothed surface delivers optimum wear

protection and an extremely low coefficient of friction, especially in applications which experience extreme pressure,

shock loads, vibrations or low speeds. TGOA PD helps to protect against scuffing and shock loading, while maintaining

a high load carrying capacity, and can help prevent the progression of micro-pitting in pre-damaged gears.

Specific grades within the Optigear 1100 range meet the requirements of DIN 51517 part 3 CLP and the requirements of

a wide range of industrial bodies and equipment manufacturers.

Application

Optigear 1100 oils are particularly valuable in the running-in phase as well as in applications where surfaces have

already been damaged in the micro-range.

Typical applications are spur, helical, herringbone, bevel and planetary gears as well as in geared couplings. Optigear

1100 gear oils may be used in rolling and sliding bearings. Particularly suitable for Heavy duty reciprocating pumps for

drilling mud or cement placement offshore and onshore drilling sites. Optigear 1100 oils have good water separation

properties.

Advantages

Compared to conventional non-PD oils, Castrol Optigear 1100 can deliver the following advantages:

Tests have shown a reduction in the coefficient of friction of up to 60% over conventional oils without PD

technology1 which can deliver energy savings, lower lubricant and component temperatures and improve

operational efficiency

In laboratory tests Castrol PD additives were shown to prevent the progression of micro-pitting in pre-damaged

gears. Non-PD oils used in pre-damaged gears showed existing wear levels increased up to three times2

Smoothing existing gear damage reduces the cost of repairs and replacements and improves operating

efficiency by increasing equipment reliability

Friction, heat and vibration are reduced

Oil with Castrol PD additives provides superior protection with wear levels of less than half those observed in

tests with conventional non-PD oil3 to help extend planned gear and bearing life

Extended lubricant service life and relubrication intervals can help to reduce costs and waste oil disposal

Full load operation is achieved in a short time, virtually eliminating the running-in period
